Measuring an Anchor Shackle (LTM Shackle) correctly is not a casual guess—it is a critical safety procedure that directly affects working load limits, fleet compatibility, and regulatory compliance. In marine and industrial rigging, even a 2 mm error in measurement can lead to pin failure, side loading, or rejected inspection certificates. At LIG MARINE GROUP, we have handled thousands of rigging inspections, and we consistently find that improper measurement is the number one cause of shackle downgrading. This guide walks through the precise measuring protocol for an Anchor Shackle (LTM Shackle) , covering every dimension that matters for safe rigging operations.
Why Precise Measurement Matters More Than You Think
An Anchor Shackle (LTM Shackle) is defined by its bow, pin, and eye geometry. Unlike standard D-shackles, the LTM type features a larger bow radius to accommodate multi-leg sling connections and angular loads. However, this same geometry makes it easier to mis-measure if you use the wrong reference points. Industry standards (ASME B30.26, DNV, and ABS) require that the Anchor Shackle (LTM Shackle) be measured under no-load conditions, at ambient temperature, and with calibrated tools. LIG MARINE GROUP recommends using digital calipers and certified tape measures, not visual estimates, for any lift plan that involves personnel or critical cargo.
The 6 Critical Dimensions for an LTM Anchor Shackle
To properly size an Anchor Shackle (LTM Shackle) for rigging, you must record six distinct measurements. The table below shows each dimension, the correct measuring method, and the tolerance range accepted by LIG MARINE GROUP quality control.
| Dimension | Measuring Method | Tolerance (mm) | Why It Matters |
|---|---|---|---|
| Bow Width (Inside) | Measure across the inner curve at the widest point | ± 1.0 | Determines sling eye compatibility |
| Bow Length (Inside) | From inner crown to inner pin seat, straight line | ± 1.5 | Affects articulation angle under load |
| Pin Diameter | Measure at three points along the pin (ends + center) | ± 0.5 | Prevents shear failure and thread stripping |
| Pin Hole Diameter | Use plug gauges; measure both ears separately | ± 0.3 | Ensures pin-to-hole clearance (critical for fatigue life) |
| Eye Thickness (each ear) | Micrometer reading at the centre of the ear | ± 0.5 | Directly relates to bearing stress on connecting hardware |
| Overall Length (pin-to-crown) | From pin head outer face to bow crown outer face | ± 2.0 | Required for stowage and clearance calculations |
Step-by-Step Measuring Procedure
Follow this sequence when you measure any Anchor Shackle (LTM Shackle) :
-
Clean the shackle – Remove paint, grease, and corrosion from all measurement points. LIG MARINE GROUP uses non-abrasive solvents to preserve the galvanized coating.
-
Zero your instruments – Calibrate digital callipers against a certified reference block before each session.
-
Measure the bow width first – Place the calliper jaws inside the bow, perpendicular to the shackle plane. Record the maximum inner width.
-
Measure the pin diameter – Take readings at the threaded end, the plain shank, and the head. Use the smallest value for your WLL calculation.
-
Check ovality – Rotate the pin 90° and re-measure. If the difference exceeds 0.5 mm, the Anchor Shackle (LTM Shackle) is deformed and must be retired.
-
Record all data – Use a dedicated inspection log. LIG MARINE GROUP provides digital templates that automatically flag out-of-tolerance readings.
Common Mistakes to Avoid
-
Measuring with the pin installed – this compresses the bow and gives artificially low width values.
-
Using a tape measure for pin diameter – always use a micrometer.
-
Ignoring surface pitting – measure at the least corroded area, but if pitting exceeds 10% of thickness, replace the unit.
-
Confusing imperial with metric – all LIG MARINE GROUP certified shackles carry dual markings, but always verify your lift plan’s unit system.
Frequently Asked Questions About Anchor Shackle (LTM Shackle) Measurement
Q1: Can I measure an Anchor Shackle (LTM Shackle) while it is still under tension in the rigging?
A1: No. You must never measure an Anchor Shackle (LTM Shackle) under load. Tension deforms the bow elastically, which can reduce the inside width by 1–3 mm depending on the WLL percentage. This false reading may lead you to select an undersized replacement. Always de-rig, lay the shackle on a flat, clean surface, and allow it to return to ambient temperature before measuring. For offshore lifts, LIG MARINE GROUP recommends a 30-minute rest period after de-rigging to stabilise the material before taking critical dimensions.
Q2: How often should I re-measure my Anchor Shackle (LTM Shackle) during its service life?
A2: LIG MARINE GROUP advises a full dimensional inspection at every 6-month interval for active rigging, and always after any shock-load event, overloading, or visible deformation. In addition, re-measurement is mandatory before each major project that exceeds 75% of the shackle’s rated WLL. Regular re-measurement tracks gradual wear, especially pin-hole ovality and ear thinning, which are early indicators of fatigue. If your Anchor Shackle (LTM Shackle) shows a dimensional change greater than 2% from its original stamped values, you should immediately remove it from service and contact a certified inspection body.
Q3: What is the correct way to measure the pin hole on an Anchor Shackle (LTM Shackle) when it has uneven wear?
A3: This is a common challenge. For an Anchor Shackle (LTM Shackle) with uneven pin-hole wear, you must take four readings per ear – at 0°, 90°, 180°, and 270° – using a set of telescoping gauges and an outside micrometer. Record the maximum and minimum bore diameters separately. The maximum bore must not exceed the nominal pin diameter by more than 3% of the pin’s nominal value (per DNV standard). If the wear is localised to one quadrant, that indicates a misalignment issue in your rigging design. LIG MARINE GROUP offers a free bore-wear assessment service for clients who send us high-resolution photographs with a scale reference alongside the Anchor Shackle (LTM Shackle) .
Documentation and Traceability
Every measurement you take should be entered into a traceable record that includes the shackle’s serial number, heat code, and original certificate data. LIG MARINE GROUP integrates our measurement logs with QR-coded labels on each Anchor Shackle (LTM Shackle) we supply, allowing instant digital retrieval of as-manufactured dimensions. This practice not only satisfies ABS and Lloyds audit requirements but also speeds up port and client inspections.
Final Verification Before Rigging
After completing all measurements, perform a cross-check: multiply your measured pin diameter by 3.14 to estimate the bearing area, then compare it with the manufacturer’s declared value. If the difference exceeds 5%, re-measure or consult the original test certificate. For high-risk lifts, LIG MARINE GROUP recommends a second inspector independently verifies all six dimensions before the Anchor Shackle (LTM Shackle) is released to the deck crew.
