              Diesel Engine (Brands Of Diesel Engines)
              • Diesel Engine (Brands Of Diesel Engines)Diesel Engine (Brands Of Diesel Engines)
              • Diesel Engine (Brands Of Diesel Engines)Diesel Engine (Brands Of Diesel Engines)
              • Diesel Engine (Brands Of Diesel Engines)Diesel Engine (Brands Of Diesel Engines)
              • Diesel Engine (Brands Of Diesel Engines)Diesel Engine (Brands Of Diesel Engines)

              Diesel Engine (Brands Of Diesel Engines)

              Product: Diesel Engine (Brands Of Diesel Engines)Compatibility with Yamaha?4strokeF2.5: 2.5hp 4stroke, upper unit same as yamaha 2.5hp 4stroke, lower unit is same as yamaha 3hp 2stroke;F4&am......

              Send Inquiry

              Product Description

              Product: Diesel Engine (Brands Of Diesel Engines)

              Compatibility with Yamaha?
              4stroke
              F2.5: 2.5hp 4stroke, upper unit same as yamaha 2.5hp 4stroke, lower unit is same as yamaha 3hp 2stroke;
              F4: 4hp 4stroke, upper unit same as yamaha 4hp 4stroke, lower unit is same as yamaha 5hp 2stroke;
              F6: 6hp 4stroke, upper unit same as yamaha 6hp 4stroke, lower unit is same as yamaha 5hp 2stroke;

              All 2stroke series are simialr with yamaha on each horsepower.
              The 9.9hp /15hp / 18hp are develop basis on ENDURO series of Yamaha, very compete and powerful.


              Warranty
              1 year for commercial usage;
              1 year for pleasure;
              1% free spare parts for each bulk order with MOQ(more than 10pcs)


              R & D Team
              OEM service available;
              All of our key engineers came from the previous BRP outboard factory of China DG, with more than 20years' experience.

              Unique Advantages
              The lowest noise compare with other same HP 2 stroke engines;
              Color of top cover are one-step moulding technology instead of painting, more flexible and more corrosion resisting;
              Most plastic& die casting parts are made by our own factory, assure the quality control.

              Series:
              Two stroke: 2.5hp; 3hp; 5hp; 6hp; 9.9hp; 15hp; 18hp; 30hp;
              Four stroke: 2.5hp; 4hp; 5hp; 6hp

              Certification
              CE/SGS/ISO 9001

              ITEM: Diesel Engine (Outboard Motor)
              Type: Outboard Engine 6hp 4stroke



              Advantages

              1. High grade marine aluminum alloy for ultimate corrosion protection
              2. Tilt & trim with shallow water drive various positions
              3. Low oil indicator for increased protection
              4. Twist grip throttle control for easy maneuverability & safety
              5. Thermostat controlled water cooling system
              6. Safety lanyard with emergency shutoff
              7. Easy forward-neutral-reverse gear shifting
              8. Vibration reduction system for smooth performance
              9. Start in gear protection for increased safety
              10. Adjustable steering friction for easier maneuverability
              11. CDI ignition system for trouble free starting
              12. Innovative large recoil wheel assists easy starting
              13. Quiet, through the propeller hub exhaust
              14. Quality 24L fuel tank with hose
              15. Colors: Jewelry blue, Pearl white, Dark grey

              Details
              Production time: 20ays after order confirm and receive 30% deposit
              CE standard, FOB Ningbo, USD currency
              MOQ: 1~10 unit
              Shade material details pls check attached quotation sheet
              Packing details as attached also
              Samples: 2 working days, we keep stock. Freight collect. Courier cost need to check with express when packing finished

              About Us
              We are Chinese professional outboard motor manufacturer. All our outboards are CE approval and our factory is ISO9001 qualified.
              Our product range is from 2.5hp to 40hp, both two and four stroke are available.

              Philosophy
              Quality First, User-oriented Management, Dedication to customer services


              Port of Load
              Ningbo, our factory is located in xiapu zone of beilun Ningbo Zhejiang China, the over street is a container storage yard. Very convenient for delivery.
              ModelF2.5AF4BF5CF6C
              DimensionOverall length623mm  (24.5in)750mm (29.5in)750mm (29.5in)750mm (29.5in)
              Overall width345mm  (13.6 in)333mm  (13.1in)333mm  (13.1in)333mm  (13.1in)
              Overall height S1021mm (40.2in)1040mm (40.29in)1040mm (40.29in)1040mm (40.29in)
              Overall height L1150mm (45.3in)1168mm (46in)1168mm (46in)1168mm (46in)
              Net weight (S/L)17KG27kg/ 28kg27kg/ 28kg27kg/ 28kg
              Gross weight (S/L)24KG35kg/ 36kg35kg/ 36kg35kg/ 36kg
              Package Size (S/L)111*44.5*49 cm³/ 124*44.5*49 cm³115*45*57.5 cm³ / 128*45*57.5 cm³115*45*57.5 cm³ / 128*45*57.5 cm³115*45*57.5 cm³ / 128*45*57.5 cm³
              Full Throttle Operating Range5250-5750 r/m4000-5000 r/m4500-5500 r/m4500-5500 r/m
              Maximum Output 1.8kw/2.5hp2.9kw/4hp3.6kw/5hp4.4kw/6hp
              Idling Speed1900±100r/m1500±50r/m1500±50r/m1500±50r/m
              TypeFour  StrokeFour  StrokeFour  StrokeFour  Stroke
              Displacement72cc139cc139cc139cc
              Bore×Stroke 54.0×31.5 mm62×46mm62×46mm62×46mm
              Ignition SystemTCICDICDICDI
              Spark PlugNGK BR7HS-10 NGK BR7HS-10 NGK BR7HS-10 NGK BR7HS-10
              Spark Plug Gap0.6-0.7mm0.6-0.7mm0.6-0.7mm0.6-0.7mm
              Control System Tiller HandleTiller HandleTiller HandleTiller Handle
              Starting System ManualManualManualManual
              Starting Carburation SystemChoke ValveChoke ValveChoke ValveChoke Valve
              Gear PositionForward-NeutralForward-Neutral-ReverseForward-Neutral-ReverseForward-Neutral-Reverse
              Gear Ratio2.08 (27:13)2.08 (27:13)2.08 (27:13)2.08 (27:13)
              Trim and Tilt SystemManual TiltManual TiltManual TiltManual Tilt
              Recommended FuelUnleaded GasolineUnleaded GasolineUnleaded GasolineUnleaded Gasoline
              Gear Oil0.075L0.1L0.1L0.1L
              Fuel Tank Capacity0.9 L1.1L1.1L1.1L
